DPM Applications in Engineering Systems: Advanced Training Package (Level 4), 8 Practical Exercises

Original price was: $1,520.00.Current price is: $299.00. Student Discount

  • Advanced DPM training package featuring 8 sophisticated ANSYS Fluent examples, specializing in combustion, spray dynamics, and reacting particles.
  • Focuses on complex combustion scenarios including liquid fuel injection, biomass combustion, and wet combustion systems.
  • Incorporates advanced spray analysis techniques, from ultra-high injection systems to evaporative cooling applications.
  • Emphasizes validation against published research and industrial data for accurate simulation results.
  • Includes comprehensive modeling approaches for reactive flows, species transport, and advanced combustion chemistry.
  • Designed for specialized CFD engineers and researchers working in power generation, combustion systems, and spray applications.
Click on Add To Cart and obtain the Geometry file, Mesh file, and a Comprehensive ANSYS Fluent Training Video.

To Order Your Project or benefit from a CFD consultation, contact our experts via email ([email protected]), online support tab, or WhatsApp at +44 7443 197273.

There are some Free Products to check our service quality.
If you want the training video in another language instead of English, ask it via [email protected] after you buy the product.
Categories: , , , , ,
Spray

Combustion Chamber by DPM Spray, CFD Simulation Ansys Fluent Training

  • The problem numerically simulates the combustion chamber by DPM using ANSYS Fluent software.
  • We design the 3-D model by the SpaceClaim software.
  • We Mesh the model by ANSYS Meshing software.
  • We perform this simulation as unsteady (Transient).
  • We use the Species Transport model to define the combustion process.
Combustion Chamber

Combustion Chamber with Combusting Particle

  • The problem numerically simulates a combustion chamber with combusting particles using ANSYS Fluent software.
  • We design the 3-D model by the SpaceClaim software.
  • We Mesh the model by ANSYS Meshing software.
  • The mesh type is Structured, and the element number equals 125000.
  • We perform this simulation as unsteady (Transient).
  • We use the Species Transport model to define the combustion process.
  • We use the discrete phase model (DPM) to define Injection into combustion chamber.



Wet Combustion

Wet Combustion Using DPM Combusting Particle

  • The problem numerically simulates the combustion chamber by DPM combusting particle type.
  • We design the 3-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software.
  • We perform this simulation as unsteady (Transient).
  • We use the Species Transport & DPM model to define the combustion process.
Liquid Fuel

Liquid Fuel Combustion Inside a Chamber Using DPM

  • In this project, liquid fuel combustion is simulated using DPM module.
  • The geometry was designed in SpaceClaim, and a mesh with 769000 elements was generated using ANSYS Meshing.
  • The species transport module is employed.
  • The fuel is ethanol and the oxidizer is nitrous oxide.
Spray Cooling Using Different Dpm Models In Ansys Fluent Center Top

Spray Cooling Comparative Analysis: Inert Particles Vs. Evaporating Droplets Using DPM

  • In this comprehensive study, three distinct cases were investigated to analyze the effectiveness of spray cooling approaches utilizing ANSYS Fluent software.
  • The simulation setup began with the creation of detailed geometry using SpaceClaim, followed by the generation of a high-quality quadrilateral mesh in ANSYS Meshing.
  • Three simulation cases were compared: baseline airflow only (Case 1), water injection with inert particles (Case 2), and water injection with  droplet interactions and phase change
  • A two-way coupling approach was employed in the DPM configurations to capture the complete interaction between the discrete phase and the continuous flow field.
Diesel Spray

Diesel Spray Ultra-High Injection, Paper Numerical Validation, ANSYS Fluent Tutorial

  • The problem numerically simulates Diesel Spray Ultra-High Injection using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software.
  • The mesh type is Structured, and the element number equals 675000.
  • This project is simulated and validated with a reference article.
  • We use the Discrete Phase Model (DPM) to define the fuel injection process.



Spray

Air Freshener Spray in Restroom CFD Simulation

  • The problem numerically simulates Air Freshener Spray in the restroom using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software, and the element number equals 1187006.
  • We perform this simulation as unsteady (Transient).
  • We use the Species Transport model to define 3 volumetric species.
  • We use the discrete phase model (DPM) to define spraying air fresheners.
  • We define an injection as the droplet that will be evaporated.



Biomass

Biomass Combustion CFD Simulation, ANSYS Fluent Training

  • The problem numerically simulates the biomass combustion process inside a gasifier chamber using ANSYS Fluent software.
  • We design the 2-D model by the Gambit software.
  • We Mesh the model by Gambit software, and the element number equals 1108.
  • We use the DPM model to define spraying the fuel in the chamber as discrete particles.
  • We define Non-Premixed Combustion in the Species model.
  • We use the P1 Radiation model to define radiant heat energy from the flames.

Special Offers For All Products

If you need the Geometry designing and Mesh generation training video for all the products, you can choose this option.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
Editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
If you want training in any language other than English, we can provide you with a subtitled video in your language.

Special Offers For Single Product

If you need the Geometry designing and Mesh generation training video for one product, you can choose this option.
If you need expert consultation through the training video, this option gives you 1-hour technical support.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
The MR CFD certification can be a valuable addition to a student resume, and passing the interactive test can demonstrate a strong understanding of CFD simulation principles and techniques related to this product.
Enhancing Your Project: Comprehensive Consultation and Optimization Services
Collaborative Development of a Conference Paper on Cutting-Edge Topics with MR CFD
Collaborative Publication Opportunity: Contribute to an ISI Article and Get Featured in Scopus and JCR-Indexed Journals
If you want training in any language other than English, we can provide you with a subtitled video in your language.

Description

Course Overview

An advanced-level training program (DPM Applications) focusing on complex combustion and spray applications, integrating sophisticated particle reactions with advanced fluid dynamics.

Module 1: Combustion Chamber Applications

Topics 1-3 cover advanced combustion modeling:

– DPM spray combustion dynamics

– Particle combustion mechanisms

– Wet combustion systems

– Advanced reaction chemistry

– Heat transfer optimization

Module 2: Liquid Fuel Systems

Topics 4-6 focus on fuel injection and spray dynamics:

– Liquid fuel combustion modeling

– Ultra-high pressure injection systems

– Numerical validation techniques

– Spray atomization physics

– Droplet evaporation models

Module 3: Specialized Applications

Topics 7-8 address practical applications:

– Environmental dispersion modeling

– Biomass combustion systems

– Species transport

– Thermal radiation effects

– Performance optimization

Learning Outcomes

Participants will master:

– Advanced combustion modeling

– Complex spray dynamics

– Reaction mechanism implementation

– Validation techniques

– Performance optimization methods

Technical Requirements

– Strong background in CFD

– Experience with reaction modeling

– Understanding of combustion chemistry

– Advanced ANSYS Fluent knowledge

– Programming skills for custom functions

This course is ideal for specialists working in power generation, engine design, and advanced combustion systems.
