Spray CFD Simulation Training Package, 8 Practical Exercises: Advanced Level

• In this comprehensive study, three distinct cases were investigated to analyze the effectiveness of spray cooling approaches utilizing ANSYS Fluent software.
• The simulation setup began with the creation of detailed geometry using SpaceClaim, followed by the generation of a high-quality quadrilateral mesh in ANSYS Meshing.
• Three simulation cases were compared: baseline airflow only (Case 1), water injection with inert particles (Case 2), and water injection with  droplet interactions and phase change
• A two-way coupling approach was employed in the DPM configurations to capture the complete interaction between the discrete phase and the continuous flow field.

This project is the CFD simulation of combustion in a bluff body mild burner.

• The problem numerically simulates Diesel Spray Ultra-High Injection using ANSYS Fluent software.
• We design the 3-D model by the Design Modeler software.
• We Mesh the model by ANSYS Meshing software.
• The mesh type is Structured, and the element number equals 675000.
• This project is simulated and validated with a reference article.
• We use the Discrete Phase Model (DPM) to define the fuel injection process.

• The problem numerically simulates the particle spraying in continuous fluid ANSYS Fluent software.
• We design the 3-D model with the Design Modeler software.
• We mesh the model with ANSYS Meshing software, and the element number equals 127,100.
• We performed the simulation in Transient (unsteady-state).
• We use the Discrete Phase Model (DPM) to define particle spraying.
• We use the User-Defined Function (UDF) to define a drag between particles and fluid.
• We use the DPM-DRAG Macro for UDF.
• We compare different Drga Laws, including Spherical, Stokes Cunningham, Non-spherical, and High-Mach.

• The problem numerically simulates the biomass combustion process inside a gasifier chamber using ANSYS Fluent software.
• We design the 2-D model by the Gambit software.
• We Mesh the model by Gambit software, and the element number equals 1108.
• We use the DPM model to define spraying the fuel in the chamber as discrete particles.
• We define Non-Premixed Combustion in the Species model.
• We use the P1 Radiation model to define radiant heat energy from the flames.

• The present problem simulates the gasification process inside a gasifier chamber by ANSYS Fluent.
• The present 3-D model is designed using Design Modeler software. The meshing of the model has been done using ANSYS Meshing software. The element number is 219170.
• Water vapor is created by the process of evaporation of water droplets inside the chamber by applying DPM.
• The species transport model with volumetric reactions has been used and to define the type of reactants and the process of chemical reactions. The CHEMKIN mechanism has been used, which includes 5 chemical reactions involving 8 different types of reactants and products.
• This model also assumes that Radiation heat transfer due to chemical reactions occurs inside the gasifier chamber, and hence, the P1 model is defined for simulation.

• This project investigates the thermal management of an electronic engine using CFD simulation through ANSYS Fluent software suite
• The primary objective was to compare the cooling effectiveness of the engine under two conditions: without water spray cooling and with water spray cooling
• The simulation workflow began with geometry creation in SpaceClaim, followed by mesh generation in ANSYS Meshing.
• The simulation framework utilised species transport modelling and implemented a two-way coupled discrete phase model (DPM) specifically for water spray simulation

• The current CFD project simulates the humidification dehumidification (HDH) system which is a model of water desalination methods via ANSYS Fluent software.
• We have designed the geometry using ANSYS Design modeler software and created the mesh on this geometry using ANSYS meshing software.
• The mesh type in the first simulation is Hybrid with 206,928 cells and Unstructured with 553,086 cells in the second case.
• The Discrete Phase Model (DPM), Species Transport Model, VOF Multiphase Model, Mass Transfer(Evaporation-Condensation), and a Porous Medium are used to analyze the project.
• Both Humidification and Dehumidification are simulated separately.
