UDF Application for Heat Analysis modeling by ANSYS Fluent: Training Package, 6 CFD Simulations

Original price was: $1,410.00.Current price is: $399.00. Student Discount

  • Arc welding heat transfer.
  • Airfoil flow control using plasma actuators.
  • Brake disk conduction heat transfer.
  • Hyperthermia therapy for cancer tissue.
  • Water-cooled PVT systems using nanofluid.
  • Trombe wall heat transfer for sustainable building design.
Click on Add To Cart and obtain the Geometry file, Mesh file, and a Comprehensive ANSYS Fluent Training Video.

To Order Your Project or benefit from a CFD consultation, contact our experts via email (info@mr-cfd.com), online support tab, or WhatsApp at +44 7443 197273.

There are some Free Products to check our service quality.
If you want the training video in another language instead of English, ask it via info@mr-cfd.com after you buy the product.

Arc Welding CFD Simulation, ANSYS Fluent

  • In this project, an Arc Welding is modeled using ANSYS Fluent.
  • A User-Defined Scalar (UDS) is added for calculating the electrical properties, and a User-Defined Function (UDF) is used for the computation of heat release from the electric field, which is added to the energy equation as a source term.
  • The geometry was created in SpaceClaim, and a mesh consisting of 335,560 elements was generated using ANSYS Meshing.

Separation Delay on Airfoil Using DBD plasma actuator, ANSYS Fluent

  • In this project, the electrical current caused by the electrical potential is modeled using ANSYS Fluent.
  • Also, the magnetic field created by the electrical current and its body force is simulated.
  • Three User-Defined Scalars (UDS) are added for calculating the electrical and magnetic properties, and five User-Defined Functions (UDF) are used for the computation of the magnetic equations' source terms, heat release from the electric field, and momentum body forces.
  • The geometry was created in SpaceClaim, and a mesh consisting of 463,701 elements was generated using ANSYS Meshing.
  • The improvement of the flow field in terms of separation on an airfoil NACA 0012 was investigated by using plasma at two velocities and angles of attack.

Brake Disk System Conduction Heat Transfer, ANSYS Fluent Simulation Training

In this project, the heat conduction of a brake disk system is modeled and simulated.

Hyperthermia Therapy of a Cancer Tissue ANSYS Fluent CFD Simulation Training

  • The present study examined blood flow in capillaries passing through a tissue containing cancerous tumors using Hyperthermia Therapy by ANSYS Fluent software.
  • We have designed the geometry using ANSYS Design modeler software and created the mesh on this geometry using ANSYS meshing software. The mesh type is unstructured with 717087 cells.
  • The whole tissue can be considered a porous medium.
  • This simulation is performed as unsteady (Transient).
  • The Source Term option is used. The UDF code defines the amount of heat applied per volume unit.



Water-Cooled Photovoltaic Thermal (PVT) System using nanofluid, Paper Numerical Validation

  • The current CFD Analysis numerically Validates the Paper "Numerical investigation on using of nanofluid in a water-cooled photovoltaic thermal systems" via ANSYS Fluent software.
  • We have designed and meshed the geometry using Design Modeler, producing structured cells.
  • UDF in SOURCE Macro  is used for the heat generation.

Trombe Wall CFD Simulation, Paper Numerical Validation, ANSYS Fluent

  • The current CFD Analysis numerically Validates the Paper "The thermal performances of a solar wall" via ANSYS Fluent software.
  • We have designed and meshed the geometry using Design Modeler and ANSYS Meshing, producing 26,550  structured cells.
  • UDF is used for the heat source in the absorber.
